Description
Mounted with braked hub F 200 W.
pitch circle 112×5, M12×1,5 (spherical)
Can be used with KNOTT type overrun brake with the same load capacity.
Additional information
| Type | VGDB20-M |
|---|---|
| Hub type | F200 |
| Pitch circle (mm) | 112×5 |
| ECE-Protokoll number of brake | 361-006-94 |
| Offset (mm) | 26-35 |
| Hub face distance 'c' (mm) | 2150 |
| Bracket center 'b' (mm) | 1700 |
| Axle base (mm) | 750 |
| Axle body size (mm) | 80×80×4 |
| c-b/2 size (mm) | 225 |
| Maximum axle load (kg) | 2000 |
| Speed limit max. (km/h) | 140 |
| Applicable din. Tyre diameter max. (m) | 0,720 |
| Applicable din. Tyre diameter min. (m) | 0,506 |
